SYSTIMAX MGS600S Cat6A Shielded Jack — Black

Name: SYSTIMAX MGS600S Cat6A Shielded Jack — Black
Brand: CommScope SYSTIMAX
SKU: 760258299

Part no. 760258299

GigaSHIELD X10D® M-Series Modular Jack, RJ45, Cat6A Shielded, Black (24 ea/pkg) Key specifications: ANSI/TIA Category: 6A. Cable Type: Shielded. Transmission Standards: ANSI/TIA-568.2-D | ISO/IEC 11801 Class EA. Remote Powering: Fully supports the safe delivery of power over LAN cabling described by IEEE 802.3bt (Type 4) and complies with the unmating under electrical load requirements prescribed by IEC 60512-99-002. Available from AmberWork Source with full manufacturer warranty and Singapore-based stock support.

Specifications

ANSI/TIA Category	6A
Cable Type	Shielded
Color	Black
Conductor Type	Solid \| Stranded
Integrated Dust Cover Type	None
Mounting	M Series faceplates
Termination Tool	JTT Termination tool
Termination Type	IDC
Transmission Standards	ANSI/TIA-568.2-D \| ISO/IEC 11801 Class EA
Wiring	T568A \| T568B
Height	16.13 mm \| 0.635 in
Width	14.44 mm \| 0.569 in
Depth	36.8 mm \| 1.449 in
Compatible Cable Diameter, maximum	8.5 mm \| 0.335 in
Compatible Insulated Conductor Diameter, maximum	1.6 mm \| 0.063 in
Contact Plating Thickness	1.27 µm
Compatible Conductor Gauge, solid	22–26 AWG
Compatible Conductor Gauge, stranded	24–26 AWG
Contact Resistance, maximum	20 mOhm
Current Rating at Temperature	1.5 A @ 20 °C \| 1.5 A @ 68 °F

Key Features

Category 6A rated
Shielded
Compliant: ANSI/TIA-568.2-D | ISO/IEC 11801 Class EA
Supports PoE (IEEE 802.3bt Type 4)
Available in: Australia/New Zealand, China, Europe, Latin America, Middle East/Africa, North America
